Superior in sound

Independent Hi-Fi system for studio-grade playback

Taking inspiration from professional-grade Hi-Fi systems, Mi Note’s dedicated sound card renders every frequency in stunning detail and transforms your music with clearer vocals, better defined instrumental passages and deeper bass. Discover a level of music that you’ve never heard before with minimal-loss, studio-grade sound quality.

Hi-Fi
audio decoder

ESS ES9018K2M
Two-stage
amplifier

Texas Instruments OPA1612
Custom ADI ADA4896
Studio
quality

192kHz/24bit
Supports
lossless formats

DSD/DXD/AIFF/FLAC/APE

4 times better than CD quality

Bringing the studio to you with 192kHz/24-bit audio

Sampling rate is to digital audio what resolution is to video and images: the higher the sampling rate, the more detail is preserved. High-quality recordings also require the right sound cards for playback. This is why Mi Note is equipped to play audio at the same 192kHz/24-bit standard used by professional recording studios. It's four times better than CD quality, giving you clarity and detail in every note.

44.1kHz / 16bit

Most phones use the same sampling rate as CDs
192kHz / 24bit

Mi Note's sampling rate is 4 times better than CD quality

Precision listening

Mobile Hi-Fi audio decoder for precision listening

Unlike most smartphones, Mi Note uses a powerful mobile Hi-Fi audio decoder instead of a single decoder chip. Its sound card, independent amplifier and range of peripheral components is similar to those in high-end Hi-Fi systems. Music is interpreted accurately with a high dynamic range and ultra-low distortion.

Standard phone audio systems
Mi Note Hi-Fi system

ESS audiophile-grade audio chip

Industry's highest performance 32-bit mobile audio DAC

The DAC, or digital-to-analog converter, is the key to music playback. It converts the digital information in a music file into audio signals, improving sound quality and increasing its volume in the process. The ES9018K2M audio chip from industry leader ESS is the mobile version of the popular ES9018 chip used in high-end Hi-Fi systems, delivering a 127dB dynamic range and maintaining a high level of clarity even at high volume levels. The -120dB THD+N standard also ensures crystal clarity up to the very top of the treble range.

Dynamic range
127dB DNR
Ultra-low distortion
-120dB THD+N
Studio grade
192kHz / 24bit
Accurate phase
Anti-jitter

Hi, fidelity!

Texas Instruments two-stage amplifier

Most phones don’t pack the power to reach high output levels and struggle with distortion at high volumes, but Mi Note handles these challenges with ease. Its professional-grade OPA1612 amplifier module enjoys a stellar reputation among audiophiles, delivering best-in-class output levels and fidelity. In addition, a customized ADA ADA4896 output amplifier helps optimize dynamic range, ensuring superb sound quality, whatever music you're into.

The lowest interference levels in its class

Two custom ADI ADA4896s
Fully balanced amplifier
The lowest distortion in its class

2 Texas Instruments OPA1612
Voltage and current hybrid drive circuits

Goes with any gear

Compatible with high-impedance headphones

Mi Note’s unique two-stage amplifier provides ample output to run headsets with impedance levels as high as 600 ohms while maintaining a high degree of quality and fidelity. Low-impedance headphones also benefit from our unique hybrid drive circuit. In fact, Mi Note has been tested with headphones of all impedance levels, and outstanding quality is guaranteed with any setup.

High fidelity performance from 8Ω to 600Ω, up to 2V output at 600Ω

A truly authentic sound

Standalone dual clock oscillators + 28 high-precision audio resistors

Digital audio involves millions of calculations every second, with any error or slowdown detracting from the overall sound quality. That’s why Mi Note is equipped with two independent audio clocks to eliminate any variations in clock timing which could interfere with audio reconstruction, and specialized audio resistors with 1/1000 precision – 10 times the precision of standard phone resistors. Every component, however small, is designed to deliver a flawless listening experience.

Dual clock oscillator

Full support for 44.1kHz and 48kHz clock frequencies

44.1kHz
series

48kHz
series
28 1‰ high precision audio resistors

Low-noise resistor membrane for higher fidelity

10x
more precise

Listen in lossless

Supports the formats favored by audiophiles

Apart from the standard MP3 format, Mi Note and the built-in MIUI music player also support lossless formats preferred by audiophiles. Listen with new ears to music without compression. It's a high-fidelity, studio-quality listening experience that's light years beyond MP3.

20 unique audio tests

Fine tuning each detail to the highest standards

Every aspect of Mi Note's Hi-Fi system has been fine-tuned and tested using a comprehensive set of 20 tests, such as minimizing interference when two different audio signals overlap. The result is a device that measures up to the standards expected of high end dedicated audio systems, ensuring that every single note you hear is of the highest quality.


						MAX
LEVEL
DETECTION

						JITTER DIGITA

						LINEARITY
DIGITAL

						DNR

						NOISE
FLOOR

						THD+N
VS
AMPL

						SMPTE

						PULSE

						DIM

						SQUARE
6K3

						SQUARE
400

						SQUARE
1K

						MULT
TONE 8

						THD+N
VS
FREQ

						FLATNESS

						CROSS TALK

						CCIF
1314

						CCIF
1920

						PHASE

						JITTER ANALOG

A Hi-Fi system in your pocket

Equipping a mobile device with professional Hi-Fi audio capabilities was no easy task – but we hope you’ll agree it was worth the effort. If you love music, we’re confident you will love Mi Note.

Low distortion
-116dB IMD
Ultra-low DANL
As low as 1.7µV
Incredible detail
123dBA dynamic range
High fidelity
THD+Noise -107dB

More about MIUI 6 > MIUI is a living system enhanced by over 100 million active users. It now packs a bigger experience for a bigger screen. Discover new functions and customizations that have been added just for Mi Note.
